- Access
RFID tag in weapon
Lock activation through kiosk
Manual override with key
Presence confirmed with photoelectric sensors - Materials
Cold-rolled welded steel
Protective plastic insert (base)
Assembled using security bolts - Finish
Tan powder coat paint - steel
Black - plastic insert - Software
Embedded access controller
Easily upgradable via ethernet connection or memory card upgrade - Dimensions
Height: 3'-6"
Depth: 1'
Width: 3'- 5-3/4" - Installation
Requires secure attachment to wall and floor
Side-by-side or stacked installation
120v AC input/15amp circuit (up to 8 units can be daisy chained)
Ethernet port on left (master rail)
Expansion port on right (master rail)
Expansion port on left (auxiliary rail)
Up to seven auxiliary rails to each master rail - Other Information
8 individual electronic locks per rail
Adjustable height to accommodate different length weapons
Verification of accessories on shotguns or long/short rifles must be confirmed when placing order for proper lock set-up on gun rack
