WatchGuard’s DV-1 is the In-Car Video system that revolutionized the way police record video. Saddled with hours of VHS tapes and painful court preparation of video evidence, agencies needed a solution that was simple to use and simple to manage.

The DV-1 is a standalone Direct-to-DVD system that requires no backend servers to operate. With advanced video capture, DVDauthoring and burning in the vehicle, the officer’s evidence leaves the car ready for court on a standard playable DVD.

FEATURES

  • Real Time DVD Recording: The DV-1 is the only In-Car Video solution on the market today that can record directly to a DVD in real time inside a moving patrol car.
  • Rugged Design: A system designed with officers in mind utilizing industrial grade components and rubber overmolding for a tough military finish.
  • Record After the Fact: Developed first by WaychGuard Video, Record After the Fact technology will allow you to go back in time, up to 20 hours, to capture video evidence that was not previously recorded. Never lose video again!
  • No Server Needed: Eliminate the need for costly servers and IT support.

Configurations

  • Overhead Mounted: Fits into virtually every police vehicle made since 2000. Customized brackets make installation simple and easy.
  • Modular System: The DVR and DVD drive are in a separate housing mounted virtually anywhere in the vehicle, with a separate control panel for a simple and easy user interface in the vehicle.

SPECIFICATIONS

System

  • Temperature Range (Boot) +10oF to + 167oF
  • Temperature Range (Operational) +19oF to +158oF
  • Operating Voltages 8.5 - 18 volts
  • Current Draw: Operational 1.5 - 2.8 amps
  • Current Draw: Power Off Max: 50 mA
  • Current Draw: Power Off Charging Microphone Average: 250mA Max: 400 mA

Console Options

  • Overhead Mounted Console
  • Dimensions (Total) 5.27” High x 6.0” Wide x 12.81” Length
  • Weight 6.25 pounds
  • Mounting Option Vehicle Specific Brackets
  • GPS Optional (integrated)
  • Crash Detection Standard, 3-axis solid state integrated sensor
  • Additional Input/Ouputs Ethernet, Radar Interface
  • Modular Recording Unit
  • Dimensions (Total) 2.85” High x 7.16” Wide x 11.27” Length
  • Weight 6.5 Pounds
  • Mounting Option Universal Bracket
  • GPS Optional (integrated)
  • Crash Detection Standard, 3-axis solid state integrated sensor
  • Additional Input/Ouputs Ethernet, Radar Interface

Video Recording

  • Number of Cameras Supported 3 (record 2 simultaneaously)
  • Resolutions 720x480 (D1), 480x480, 352x480
  • Frames per Second 30
  • Video Compression MPEG-2 (DVD-Video)
  • Recording Triggers Lights, Sirens, AUX, Crash, Wireless Microphone, Manual
  • Storage Architecture Dual Drive (Patents Pending)
  • Recording Media (Buffer) Internal 80GB Automotive Grade HDD
  • Recording Media (Removable) DVD + RW
  • Pre and Post-Event 15 seconds - 10 minutes, independently configured
  • Redundancy Record-After-The-Fact
  • Hours of Recording 75 Hours Average
  • Video Transfer Types DVD

Audio Recording

  • Number of Audio Sources Supported 3 (2 wireless, 1 wired standard)
  • Audio Compression MPEG multi channel

LED Display Unit

  • Dimensions - Overhead Overhead: Integrated into Overhead Console, Modular: 3.94” Tall x 5.03” Wide x 1.34” Deep
  • Weight Overhead: Integrate into Overhead Console, Modular: 8 ounces
  • Connection Type (Modular) DVI
  • Size 6” diagonal
  • Resolution 800 x 480
  • Illumination LED Backlit, 0-100% dimmable
  • Brightness 330 nits
  • Viewing Angle 140o H and 130oV
  • Typical Contrast Ratio 500:1
  • Keys/Buttons One piece rubber over-molded
  • LED Indicators Power, Menu, Record, Stop, Review, Volume (+ and -), Brightness (+ and -), Cameras (1-4), Microphones (1-4)
  • User Interface Full graphical user interface
  • Mounting Options Overhead: Vehicle Specific Brackets Modular: RAM or Panavise Universal Mounting Options
